2.4GHz Active Tag
Model NO.：
HZ801
Key Features
Ultra-low-power, average working current<3.5uA.
Small size design suit for IT assets, valuable items, equipment and instruments
2.4G identify range can reach 80 meters, reading range adjustable via software.
Contact anti-tamper/mechanical anti-tamper, alarm signal will send out once removed from object.
Parameters
Model No | HZ801 |
Type | Beacon type, RF power 4dBm |
Inductive mode | Initiative transmit, transmit every 10 second |
Material | ABS, heat resistant ,Black Color |
Dimension | 44.5*19*9.5mm |
Weight | 9.1g |
Battery | Battery life 5 years (signal time interval is 10s) |
IP Grade | IP54 |
Signal Modulation Mode | GFSK |
Communication Speed | 1Mbit/s |
Operating Frequency | 2.44GHz |
Average Current | <3.5uA |
Battery mode | CR1632 |
Operating Temp | -20℃~+60℃ |
Storage Temp | -40℃~80℃ |
