2.4G Rugged Assets Mount Tag
Model NO.：
MR3837C
Key Features
Suitable to adopt fixed frequency working mode, with powerful anti-jamming ability;
Effective reading range up to 400m (working with reader model MR7901P, open air environment. depend on reader and antenna, software configurable);
Super wide working band design, conforming to relevant industry rules and also flexible in application development;
Multiple-tag reading at the same time , no limitation or interference by tag quantity in the reading range.
Ultra-low power consumption，average working current<15uA
Typical application are Safe City Electric Bike tracking, Motorcycle Tracking, Tunnel and Miners Security Monitoring, IT Assets Tracking, Construction Raw Material Inventory etc.
Parameters
Model No | MR3837C |
Operation frequency | 2402-2483MHz |
Type | Beacon Type |
Signal modulation | GFSK |
Communication speed | 1Mbit/s |
Inductive mode | Initiative Transmit, Transmit Every 1s |
Output power | 7dbm |
Material | ABS, Heat Resistant , |
Dimension | 40MM*40MM*10.8MM |
Battery | Battery Life Up to 3 years |
IP Grade | IP67 |
Installation | Fixed installation, hidden installation, screw |
Color | Gray |
Weight | 14g |
Unique ID | 4 bytes Data in HEX, Lester Marking |
Battery model | CR2450 |
Battery capacity | 550mAh/3V |
Operating temperature | -20℃~+45℃ |
Storage temperature | -30℃~+65℃ |
Operating humidity | 10%～80% |
Storage humidity | 10%～95% |
